Plovákový spínač hladiny FLS-S, ARV2"-VUU-L245/12-V52A, 2 spínače 155mm /190mm SPDT

ARV2"-VUU-L245/12-V52AFloat Switch Type FLS-SAMaterial: Stainless steel 316Ti (EN 1.4571)Pressure: 1 barTemperature range: -10°C up to 80°CFluid density: 1000 kg/m3Housing: Aluminium Ingress protection: IP65Electrical connection: M20 x 1.5 mm with cable gland Process connection: Mounting thread downwards 2"BSP Switch function 1: Change-over (SPDT) 155 mmSwitch function 2: Change-over (SPDT) 190 mmSwitch rating: max. AC 230V; 40VA; 1A / DC 230V; 20W; 0.5AFloat: Stainless steel 316Ti V52A; Float outer diameter: 52 mmNumber of floats: 1 pcGuide tube: OD 12 mm Insertion length (L): 245 mmFloat stop: Welded pegWeight: 1,2 kgProcess connection: Mounting thread downwards 2"BSP Switch function 1: Closing on rising level (SPST) 60 mmSwitch rating: max. AC 50V; 100VA; 1A / DC 75V; 50W; 0.5AFloat: Stainless steel 316Ti V44ANumber of floats: 1 pcGuide tube: OD 12 mm Insertion length (L): 105 mmFloat stop: Float strapWeight: 1,1 kg
