kapilárový teploměr se 2-ma spínacími kontakty
kapilárový teploměr s přední přírubou a 1 spínacím magnetickým kontaktem
Model: SC15, Combistat Nominal size [NG, d1]: 80 mm Unit: °C Scale range: 0 °C ... 150 °C Case material: Plastic, black; Mounting option: Panel mounting with clamp Ingress protection: IP53 (front), IP00 (rear) Contact type: 1 adjustable change-over switch Switch rating: 5 A non-inductive at max. 250VAC 40-60Hz Cable connection: terminal block SWITCH ADJUSTMENT: adjusting knob Capillary length: 0.5 m Capillary material: Copper braided Connection design: plain stem (BF1/SF94) Stem diameter [d5]: 6 mm Insertion length [L1]: 300 Stem material: Copper alloy Bend protection: Bend protection on tube and case side dial background: White Data sheet: TV28.02
V70.55.100 0 °C ... 120 °C CL.2 Connection design: union nut (BF3/SF97) G1/2 female Tauchsft: L1=100 x 8 mm Capillary length: 1 m Stainless steel Window: laminated safety glass Contact type: 1 adjustable change-over switch 5A/48VAC cable box; *WIKA* dial background: white Data sheet: TV28.01
V70.55.100 0 °C ... 160 °C CL.2 Connection design: union nut (BF3/SF97) G1/2 female Tauchsft: length is calculated automatically x 8 mm Capillary length: 2 m Stainless steel Window: laminated safety glass Contact type: 2 adjustable change-over switches 5A/48VAC cable box; *WIKA* dial background: white Data sheet: TV28.01
Celonerezový teploměr průměr 100mm s 1 spínacím elektronickým kontaktem, zadní vývod stonku průměr 8mm, délka 400mm, třída 1%, 0-120°C
Celonerezový teploměr průměr 100mm s 1 přepínacím elektronickým kontaktem 5A/48VAC, spodní vývod stonku průměr 8mm, délka 400mm, třída 2, 0-120°C
V70.55.100 0 °C ... 120 °C CL.2 Connection design: union nut (BF3/SF97) G1/2 female Tauchsft: length 100 / 8 mm Capillary length: 3m Stainless steel Window: laminated safety glass Contact type: 2 adjustable change-over switches 5A/48VAC cable box; *WIKA* dial background: white Data sheet: TV28.01
Celonerezový teploměr průměr 100mm s 1 spínacím elektronickým kontaktem, spodní vývod stonku průměr 8mm, délka 400mm, třída 1%, 0-120°C
kapilárový teploměr se 2ma spínacími kontakty
